Foil Drive

Sunova Foil Drive Board.

Pre-Oder Now For October delivery!

Sunova has teamed up with Foil Drive to make the ideal board to release quickly from the water and reduce the amount of thrust needed from the Foil Drive, giving you longer battery life. Get  more waves and have more fun. Sunova Foildrive boards by their design also make for excellent mid-lengh foilboards for prone foiling.

4'8 X 18.5" 39L

4'11 x 19" 44L

5'3 x 19.5" x 49.8L

5'6 x 19.5" 62L

Foil Drive Three Blade Propeller Hub Set.

Looking for just a little more torque to get out of the water easier?

Designed to increase low end thrust, the Three Blade Propeller Hub is an optional upgrade for Foil Drive Assist PLUS units, a game changer for riders pushing the limits of rider weight, board size and foil size.

When compared to the standard Two Blade Propeller system, the NEW Three Blade Propeller system improves performance by:

• Increased low end thrust. The extra blade helps push more water
• More torque at lower RPM, avoiding propeller cavitation under high load
• More effective surface driving when the props breach the surface
• A smoother, quieter ride due to lower RPM

It is specifically designed for riders who require more low end torque, whether this is due to using a low volume board, a smaller or higher aspect foil than normal, or being a heavier rider.

Foil Drive do not recommend using the Three Blade Propeller Hub for prolonged efoiling at full throttle as this will drain your battery much quicker, and could cause the electronics to go into thermal overload protection. The three blade propellers will draw more watts / power that the two blade prop that can " unload " at full throttle when on foil. Do NOT use three blade prop above 90% throttle continuously when efoiling. You must let the ESC in the box cool in the water from time to time.

Included with Three Blade Propeller Hubs is a range of hardware, with two options of bolts, Standard Propeller Bolts and new Button Top Bolts:

3x M3 30mm 2.5mm Standard Propeller Bolts can be used, these are the same as propeller bolts used on the 2 blade hub. Alternatively, 3x M3 30mm 2mm Button Top Propeller Bolts can be used to improve hydrodynamics, a secondary tool required. As they are not in the flow of water, they do not cause formation of small bubbles that then enter the prop.

The smaller Button Top Bolts require a 2mm Allen Key and cannot be used with your existing 2.5mm Driver that comes standard with all Foil Drive kits.

Note:

• Not compatible with Foil Drive Assist. While they do fit, these propellers require the higher RMP of the Assist PLUS in order to improve performance.
• Three Blade Propeller Hubs must be used with three propellers!

Foil Drive 40V Fast Charger 8 AMP.

Recharge Gen2 Foil Drive Batteries in less time with the 40v FAST Foil Drive Charger 8A. With 8A of power output, this charger ensures a quick and efficient charge.

Foil Drive Dielectric Battery Grease MUST be used on all connections (Battery and Motor Plug) before every use to ensure a reliable connection between unit and motor cable, protecting against corrosion, heat, and oxidation.

Foil Drive Dielectric Grease has been specifically selected for the product and environmental use case. Only use Foil Drive Battery Grease as Foil Drive cannot guarantee the reliability of third party grease, this can void your warranty.

When compared to the standard Two Blade Propeller system, the NEW Three Blade Propeller system improves performance by:

• Increased low end thrust
• More torque at lower RPM, avoiding propeller cavitation under high load
• More effective surface driving when the props breach the surface
• A smoother, quieter ride

The Foil Drive Assist MAX Power with AXIS integration.

This collaboration is for the AXIS rider who wants to embrace their Foil Drive, while preserving the streamline, highly responsive design of the AXIS masts. Designed for the entire foil line, the AXIS masts are stiff, strong, and ready for any use and conditions.

While motor positions are fixed and cannot be changed once installed, the Axis x Foil Drive Mast Integration is perfect for riders who know exactly where they want their motor, and never want to move it.

MAST DOES NOT INCLUDE A DOODAD / FUSELAGE ADAPTOR.
